Aluminum coated Coil for gutter Alloy:1050,1060,1100,3003,3105

Aluminum Coil

Aluminum coated Coil for  Gutter Quick Detail

Substrates: Aluminium (1100, 3003, 3004, 3105, 5005, 5052, 8011, 8079), etc.
Thickness: 0.08-1.5mm
Width: <1800mm
Coils core diameter: 150mm ,405mm, 505mm, 508mm, 510mm
Coating thickness: PVDF >=25micron POLYESTER>=18micron
Color standard: E < 2 or it is not obvious by eyeballing
Pencil hardness: > 2HB
Coating adhesive: not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993)
Bend stength: >100 times
Boiling point: no any distortion and color change (in the 99 more or less 1 degree
water, then cooling 2 hours)
Corrosive: surface deep in the 5% muriatic acid and 5% NaCL, interior deepin the 2% muriatic
 acid and 2% NaCL, after 48 hours, no change


Aluminum coated Coil Gutter Packaging/Delivery

Packaging Detail: export standard, wooden plate
Delivery Detail: within 30 days after receiving L/C or deposits


Aluminum  coated Coil  for Gutter Applications

  • Exterior applications such as: Wall cladding, facades, roofs and canopies, tunnels, column covers or renovations
  • Interior applications such as: Wall cladding, ceilings, bathrooms, kitchens and balconies
  • Advertisement and market applications such as: Display platforms, signboards, fascias and shop fronts
  • Transport and industry application

Aluminum Coil


Color Match of Coated Aluminum Coil
1. For custom' color requests, we can deal as following:
  • Supply a physical sample of custom color. A color sample on metal is preferred. If other, it is also acceptable. But the color matching rate may be not good as color on metal
  • New color sample is usually offered by our paint supplier in 5-7 days, special color should be in 7-10 days
  • Upon receipt of color sample, please approve in writing as soon as possible. Once you approved, we will arrange purchasing and production

Note: Color difference maybe occurred in different production batch, so it is suggested all panels are placed in one order for same project. And keep same direction as arrow on protective film when
installing to avoid any color difference by vision.

2.For general colors, please refer to our color chart.

About the  Coated Aluminum Coil
Coated aluminum coil refers to the aluminum coil through coating and coloring treatment generally includes PE coated aluminum coil and PVDF coated aluminum coil.Coated aluminum coil is widely
 used to manufacture aluminum composite panel, aluminum ceiling, roofing, aluminum veneer, signboards,gutter.
